Water Bottle Washer
In busy laboratory animal centers, water bottles are numerous, changed frequently, and difficult to clean by hand due to their narrow necks. The IVC500 Water Bottle Washer is purpose-built for batch cleaning of laboratory animal drinking bottles.
Phone Consultation
Follow us
- Introduction
- Features
- More Recommendations
Introduction
Using hot water, high pressure, and high-flow spray, it effectively removes feed debris, contaminants, and microorganisms from inside and outside each bottle — delivering clean, hygienic bottles that meet the stringent safety requirements of laboratory animal drinking water.
Features
Powerful Cleaning Performance：Hot water, high-pressure, high-flow spray achieves fully automatic bottle cleaning. An imported circulation pump and rotating spray arms ensure one-to-one spray coverage of both inner and outer bottle surfaces — removing dirt and residue with outstanding results.
Fast Batch Processing：A single cycle takes just 3–4 minutes and washes 2 baskets simultaneously — up to 36 bottles per cycle. This high throughput keeps your animal facility running smoothly and dramatically boosts operational efficiency.
Energy & Water Efficient：An independent rinse water tank, circulating heating system, and waste-water heat recovery design minimize energy and water consumption. Final rinse water is recycled — delivering both cleanliness and cost-effective, eco-friendly operation.
User-Friendly Operation：Siemens PLC and touchscreen control provide a simple, intuitive interface with freely adjustable parameters. The system accommodates multiple bottle sizes and runs stably and reliably — ideal for daily use in research institutes and animal facilities.
Fast Batch Processing：A single cycle takes just 3–4 minutes and washes 2 baskets simultaneously — up to 36 bottles per cycle. This high throughput keeps your animal facility running smoothly and dramatically boosts operational efficiency.
Energy & Water Efficient：An independent rinse water tank, circulating heating system, and waste-water heat recovery design minimize energy and water consumption. Final rinse water is recycled — delivering both cleanliness and cost-effective, eco-friendly operation.
User-Friendly Operation：Siemens PLC and touchscreen control provide a simple, intuitive interface with freely adjustable parameters. The system accommodates multiple bottle sizes and runs stably and reliably — ideal for daily use in research institutes and animal facilities.
Applications
Suitable for universities, research institutes, and pharmaceutical laboratories requiring efficient cleaning of daily-use water bottles for mice and rats. Reduces manual labor while improving cleaning efficiency and hygiene consistency.Technical Specifications
| Parameter | Specification |
|---|---|
| Power Supply | 380V, 50Hz, 3-phase + neutral + ground |
| Wash Cycle | 3–4 min |
| Max Capacity per Cycle | 36 bottles |
| Main Wash Pump Flow | 500 L/min |
| Rinse Pump Flow | 100 L/min |
| Wash Temperature | 55°C |
| Preheat Tank Power | 9 kW |
| Rinse Tank Power | 6 kW |
| Display | 4.3" color touchscreen |
| Certification | CE |
